2006 Haulotte HA20PX : Sell Offer

Machine Details Machine Type Boom Lift Usage Hours 792 Engine Make Deutz; Engine Model F 4L 2011 ; Fuel Diesel Paint Not Original paint Tires 385/65x22.5 Attachments N/A Machine description Open operator station, hydrostatic drive, 230 Kg max lift capacity, 20m max lift height Other specifications Power KW/HP 42KW/56.3HP Operating Weight 11710 kg Max Working Height 20650 mm Max Platform Height 18650 mm Max Horizontal Reach 13500 mm Max Platform Weight Capacity 230 kg Platform Length 1800 mm Platform Width 800 mm Platform Rotation 180 degrees Overall Length 8930 mm Overall Width 2380 mm Overall Height - mast lowered 2670 mm Wheelbase 2800 mm Turning Radius 3900 mm Ground Clearance 420 mm
