Rate loading weight kg 1500 Rated bucket capacity m3 0.5 Unload height mm 2400 Max climb ability 21% up time (S) 6 Travel speed Low speed shift (km/h) 5 Low speed shift (km/h) 25 Min turning radius (m) 4.2 Overall dimension (length X width X high) mm 5200x1690x2400 Bucket width mm 1600 tread mm 2010 Wheelbase mm 1330 Minimum ground clearance mm 200 The weight of machine kg 3300 Engine Model 485 Rate power kw 26 Rated speed r/min 2200 Start-up mode 12V DC Motor Drive Second, the work of installation of hydraulic system pump Model CB-Fc40 Rated pressure Mpa 16 Multi-way valve Model 34DLS-E10L Rated pressure Mpa 25 Max flow ( L/MIN) 80 Priority valve Model YXL-F160L-N
